BOSSGSM-AP21
21dBi 1.7-2.1GHz DCS/UMTS/LTE 4G antenna
The BOSSGSM-PDU21 is a High Gain Point-to-Point Antenna designed for use in high RF density environments. Excellent radiation characteristics are the distinguishing features of these well priced antennas. This family of grating antennas is designed for harsh environments with high winds.
Antennas with the best weight to strength ratio, wind tunnel tested at 300 km/h.
features:
- Welded steel grating
- Maximum wind resistance
- Hot-dip galvanized wire, will not rust
- 14G wire in 12,5 x 25 mm mesh.
- Gain 21 dBi
- Polarization: vertical / horizontal interchangeable.
- Bandwidth 3 dB: 12º.
- Polar crossover ratio 26 dB
- Front / rear ratio 28 dB
- Maximum power 50 W
- Impedance: 50 Ω
- VSWR: 1.8:1
- Size 76 x 76 cm
- Wind effect at 216 Km/h: 476
- Weight 3 Kgrs
- N female connector
